Marantz PM8006 Integrated Stereo Amplifier

  • Sale
  • Regular price $3,150.00

*This product cannot be purchased online. Please call, email or message using any of the buttons below to get in touch and place an order.*

Living Entertainment North Coast


Marantz SR8015 11.2 Channel 8K AV Receiver

INTEGRATED AMPLIFIER WITH NEW PHONO-EQ

Manufacturers Details:

Current Feedback

Current Feedback amplification is a well-known, Marantz-original circuit technology, thoughtfully designed to match the requirements of Super Audio hi-res music for wide-bandwidth, high-speed reproduction. The impedance at the Current Feedback point is limited, generating a very low phase shift. Marantz Current Feedback amplifiers reduce the need for phase compensation by minimizing Negative Feedback (NFB). This simplifies the signal path and results in a high through-rate, excellent transient response and superb sonic transparency across the full bandwidth. Unlike conventional Voltage Feedback topology, Current Feedback also makes the power amplifier insensitive to difficult loudspeaker loads.

Marantz HDAM Technology

Marantz developed its own discrete circuit boards called Hyper-Dynamic Amplifier Modules, or HDAMs, to replace the chip based amps used elsewhere. Using discrete surface mount components with short mirror-image left and right signal paths, HDAMs outperform the regular integrated Op-amps dramatically in Slew Rate and noise level. The result is much more dynamic, accurate and detailed sound. Over the years, Marantz has developed different HDAMs to fit the particular requirements of players and amplifiers. The PM8006 uses the high-grade SA3 version.

Engineered With Care:

Marantz Musical Phono EQ

For a long time, Marantz integrated amplifiers have featured high-quality phono stages. We’ve elevated our commitment to vinyl with the Marantz Musical Phono EQ stage, as seen in the PM8006 amplifier. Enjoy the very best playback of all music sources, be they digital or analog. Marantz Musical Phono EQ uses two-stage amplification, allowing less gain per stage for lower distortion. The PM8006 combines Marantz HDAM technology with JFETs (junction gate field-effect transistors) in the input stage, providing high input impedance that eliminates the need for AC coupling capacitors and simplifies the signal path, vastly improving the signal purity overall.

Toroidal Transformer

A Toroidal transformer offers several advantages that derive from its efficiency and power capability. The shape of it lends to low levels of electromagnetic radiation and mechanical vibration, producing improved sound quality over what you might experience with dated transformer models.

Key Features:

Integrated For Maximum Power
Integrated Current Feedback Amplifier with 2x 70W / 8 ohm rms

    Smooth Volume Control
    Newly designed electric volume circuit

    Marantz-Pure Vinyl
    Exceptional Marantz Musical Phono EQ stage

    Smoother More Marantz Sound
    Marantz proprietary HDAM-SA3 circuits

    Specifications:

    Number of Channels

    2
    Power Rating
    70 W per channel @ 8 Ohms RMS
    100 W per channel @ 4 Ohms RMS
    Frequency Response
    5 Hz to 100 kHz
    Signal to Noise Ratio
    MM: 87 dB
    High Level: 106 dB (2 V input)
    Power Amp Direct In: 125 dB
    Total Harmonic Distortion (THD)
    0.02%
    Damping Factor
    100
    Input
    6 x stereo RCA L/R (1 MM phono)
    1 x stereo RCA L/R power amp direct
    Output
    1 x 1/4" (6.35 mm) headphone (front)
    1 x stereo RCA L/R
    1 x stereo RCA L/R pre-out
    Speaker Connectors
    4 x binding post pairs
    Other Connectors
    1 x RCA remote in
    1 x RCA remote out
    1 x AC power inlet
    1 x ground terminal
    Input Sensitivity
    MM: 2 mV / 47 kOhms
    High Level: 200 mV / 20 kOhms
    Power Amp Direct In: 1.6 V / 15 kOhms.
    Power Requirements
    120 VAC, 60 Hz
    Power Consumption
    Operational: 220 W
    Standby: 0.2 W
    Dimensions (W x H x D)
    440 x 128 x 379 mm
    Weight (Approximate)
    12 kg
