Yamaha A-S1200 Intergrated Amplifier
Specifications
| Maximum Power (4 ohms, 1kHz, 0.7% THD, for Europe) | 160 W + 160 W |
| High Dynamic Power/Channel (8/6/4/2 ohms) | 105/135/190/220 W |
| Rated Output Power | [20 Hz-20 kHz, 0.07% THD] 90 W + 90 W (8 ohms), 150 W + 150 W (4 ohms) |
| Frequency response 20 Hz - 20 kHz | +/-1 dB |
| Damping Factor | ≧ 250 (1 kHz, 8 ohms) |
| Frequency Response | +0 / -3 dB (5Hz-100kHz) , +0 / -0.3 dB(20 Hz-20 kHz) |
| RIAA Equalization Deviation | +/-0.5 dB (PHONO (MM/MC) |
| Total Harmonic Distortion (20Hz to 20kHz) | [Input 0.5 V] PHONO MC→LINE2 OUT: 0.02% (1.2 mVrms), PHONO→LINE2 OUT: 0.005% (1.2 Vrms), CD, etc.→SP OUT: 0.035% (50 W/8 ohms) |
| Signal-to-Noise Ratio | PHONO MC: 90 db, PHONO MM: 96 dB, CD, etc.: 110 dB |
| Input Sensitivity | [1 kHz, 100 W/8 ohms] PHONO MC: 150 uVrms/50 ohms, PHONO MM: 3.5 mVrms/47 kohms, CD, etc.: 200 mVrms/47 kohms, MAIN IN: 1 Vrms/47 kohms |
| Tracking force, recommended | 2.0 grams |
| Transformer | 625VA (Toroidal) |
| Dimensions (W x H x D) | 435×157×463 mm; 17-1/8 x 6-1/8 x 18-1/4 |
| Weight | 22.0 kg; 48.5 lbs |
Shipping & Returns
We offer free shipping on any order over $150. For full details please see our Shipping Policy.
Our returns policy lasts 30 days. If 30 days have gone by since your purchase, unfortunately, we may not be able to offer you a refund or exchange. For full details please see our Refund Policy.

Yamaha A-S1200 Trade-In
Acknowledging the golden era of Hi-Fi with the level meters and beautiful design, the A-S1200 boasts an impressive array of the latest technology to accurately deliver an emotional, purely musical sound.
- High Quality Components delivering exceptional musical expression
- Toroidal power transformer with enormous energy for a pure musical sound
- Gorgeous level meters convey dynamics and music pulse with a nod to the nostalgic Hi-Fi era
- Floating Balanced Power Amplifier
- Mechanical ground concept maximises rigidity for expressive and rhythmic bass
Trade-In Product
- Minor wear
- Minor marks on the front and back
- No original box
- Tested and working.
