Pro-Ject Phono Box E
Phono Box E accepts MM cartridges and offers an audiophile music experience at an entry level price. Advanced circuitry and SMD construction keep noise and distortion at a surprisingly low level. A built-in internal shielding and an outboard DC power supply leave no risk for external interference.
Because of it's small casing, the Phono Box E can be placed near the turntable or hidden away. Input and output sockets are gold-plated for preservation of quality. Phono Box E can be connected easily to a line-input (AUX etc) of your amplifier.
Manufacturers Details:
Today, many amplifiers do not have a specific phono cartridge input. Phono Box E is an ideal phono preamplifier for these hifi systems. Phono Box E accepts MM cartridges and offers an audiophile music experience at an entry level price. Advanced circuitry and SMD construction keep noise and distortion at a surprisingly low level.
Engineered With Care:
A built-in internal shielding and an outboard DC power supply leave no risk for external interference. Because of its small casing, Phono Box E can be placed near the turntable. Input and output sockets are gold-plated for preservation of quality. Phono Box E can be connected easily to a line-input (AUX etc) of your amplifier.
Key Features:
- Amplification and RIAA equalisation for MM cartridges
- Design principle inspired by Dr. Sykora
- SMD circuitry
- Special low noise components
- Internal metal shielding
- Small size allows installation close to record player
- Gold plated RCA connection sockets
- Outboard power supply included
Specifications:
Input impedance: | 47 kohms |
Input capacitance: | 120 pF |
Gain: | 40 dB |
Output voltage(typically): | 500mV/ 1kHz at 5mV/1kHz |
Noise floor: | 88 dB (A weighted) |
THD: | <0,05% |
RIAA deviation: | deviation max. 0.5 dB/ 20 Hz - 20 kHz |
Input: | 1 pair RCA socket |
Output: | 1 pair RCA socket |
Outboard power supply: | 18 V/500 mA DC; 220 - 240 V, 50 Hz |
Standby power consumption: | < 1 watt |
Power consumption: | 20 mA DC |
Dimension W x H x D (D with sockets): | 120 x 32 x 100 (106) mm |
Weight: | 269 g without power supply |
