Ortofon Concorde 5S Moving Magnet Cartridge
Specifications
Channel balance at 1 kHz | < 2 dB |
Output voltage at 1 kHz, 5cm/sec | 4.5 mV |
Channel seperation at 1 kHz | 20 dB |
Frequency response 20 Hz - 20 kHz | +/- 3 dB |
Compliance, dynamic, lateral | 20 µm/mN |
Stylus type | Elliptical diamond on Aluminium cantilever |
Stylus tip radius | R 18 µm |
Tracking force, recommended | 1.8 g |
Internal impedance, DC resistance | 750 Ω |
Cartridge colour | Black |
Cartridge weight | 18.5 g |
Recommended load resistance | 47 kΩ |
Coil wire material | OFC |
Warranty
Shipping & Returns
We offer free shipping on any order over $150. For full details please see our Shipping Policy.
Our returns policy lasts 30 days. If 30 days have gone by since your purchase, unfortunately, we may not be able to offer you a refund or exchange. For full details please see our Refund Policy.

Ortofon Concorde 5S Moving Magnet Cartridge
Sale price$139.00
Regular price$139.00 (/)
TELL ME MORE ABOUT THE
Ortofon Concorde 5S Moving Magnet Cartridge

Iconic design

Stylus

Rubber suspension

Coil system

Compatibility
