Michi X430 Integrated Amplifier

“When the bass kicked in, it seemed to sound very muscular and powerful.” Andy Madden
Specifications
| Dimensions (W × H × D) | 431 x 148 x 422 mm / 17 x 6 3/5 x 15 5/6 |
| Front Panel Height | 131 mm (5 1/6 |
| Power Requirements | 120 V, 60 Hz |
| Power Consumption | 520 W |
| Standby Power Consumption | Normal < 0.5 W / Network wakeup < 2 W |
| Net Weight | 16.9 kg (37.26 lbs.) |
| BTU Rating | 1476 BTU/h |
| Power Output (FTC) | 220 W/Ch (8 ohms) |
| Maximum Power Output (Non FTC) | 340 W/Ch (4 ohms) |
| Continuous Power Output (Non FTC) | 210 W/Ch (8 ohms) |
| Total Harmonic Distortion | < 0.03% |
| Frequency Response | Line Level Inputs: 10 Hz - 100 kHz (+0 dB, -0.5 dB) Digital Inputs: 10 Hz - 20 kHz (+0 dB, -0.4 dB Max) Phono Input: 20 Hz - 20 kHz (+0 dB, -0.5 dB) |
| Signal to Noise Ratio (A Weighted) | Line Level Inputs (RCA): > 105 dB Line Level Inputs (XLR): > 100 dB Digital Inputs: > 110 dB Phono Input: > 80 dB |
| Intermodulation Distortion (60 Hz:7 kHz, 4:1) | < 0.03% |
| Damping Factor (20 Hz - 20 kHz, 8 ohms) | 260 |
| Channel Separation | > 55 dB |
| Preout Level | 1.92 V |
| Output Impedance | 100 ohms |
| Tone Controls | ±10 dB at 100 Hz / 10 kHz |
| Input Sensitivity | Line Level Inputs (RCA): 356 mV Line Level Inputs (XLR): 743 mV Digital Inputs: 0 dBfs Phono Input (MM): 5.56 mV |
| Input Impedance | Line Level Inputs (RCA): 100k ohms Line Level Inputs (XLR): 50k ohms Digital Inputs: 75 ohms Phono Input (MM): 47k ohms |
| Input Overload | Line Level Inputs (RCA): 4 V Line Level Inputs (XLR): 10 V Phono Input (MM): 66 mV |
| Digital to Analog Converter | ESS ES9039Q2M DAC |
| HDMI | Support CEC with ARC function 2-channel PCM only (up to 24-bit/48 kHz) |
| Coax/Optical Digital Input Signals | SPDIF LPCM (up to 24-bit/192 kHz) |
| PC-USB | USB Audio Class 2 (up to 32-bit/384 kHz) *Driver installation required Supports DSD (up to 4X, 11.2 MHz) and DoP (up to 2X, 5.6 MHz) Supports Roon Tested |
Warranty
Shipping & Returns
We offer free shipping on any order over $150. For full details please see our Shipping Policy.
Our returns policy lasts 30 days. If 30 days have gone by since your purchase, unfortunately, we may not be able to offer you a refund or exchange. For full details please see our Refund Policy.

TELL ME MORE ABOUT THE
Michi X430 Integrated Amplifier

High-Power Class AB Amplification

ESS SABRE ES9039Q2M 32-bit DAC

Ultra-Low Distortion Performance

High-Resolution Audio Support

Flexible Modern Connectivity

Premium Michi Design and Engineering
“When the bass kicked in, it seemed to sound very muscular and powerful.”
